Horizontal machining centre 101306

Name: Horizontal machining centre 101306
SKU: 101306

0 EUR

bookmark Write a note

Print page

General information

Creation date 06.03.2025
Ad-ID 101306

Search criteria

Number of NC-axis 3 Items
Traverse X-axis 500 mm
Traverse Y-axis 560 mm
Traverse Z-axis 500 mm
Workpiece weight max. 250 kg
Workpiece width max. 530 mm
Workpiece height max 760 mm
Main spindle speed max. 15000 rpm
Tool interface [type] BT-40 HSK-A63 SK-40
Tool stock min. (standard) [items] 60 Piece
Control (manufacturer) Fanuc G-Tech 31 iB
Machine manufacturer (list selection) nomen nominandum

further specifications

X-Y-Z-axis rapid linear traverse max. 60/60/60 m/min
Tool diameter max. 150 mm
Tool length max. 300 mm
Tool weight max. 8 kg
Main spindle power max. (100% c.d.f.) 7.5 kW 15.0 kW
Main spindle torque max. (100% c.d.f.) 120 Nm

Contact us

First name *

Surname *

E-mail address *

Your message *

The personal data you provide will be forwarded directly to the provider for the purpose of establishing contact. It will not be stored by us.

Notes on privacy policy

Report ad

Reason *

E-mail address *

Your message *

The personal data you provide will be forwarded directly to the provider for the purpose of establishing contact. It will not be stored by us.

Notes on privacy policy

Description

The horizontal machining centre is ideal for the automated production of a wide range of workpieces. It offers outstanding accuracy and excellent surface quality combined with high cutting performance. A tool magazine with up to 520 places is available for flexible production, allowing small and medium-sized series to be manufactured efficiently and adaptably.
