Horizontal machining centre 101308

Name: Horizontal machining centre 101308
SKU: 101308

0 EUR

bookmark Write a note

Print page

General information

Creation date 06.03.2025
Ad-ID 101308

Search criteria

Number of NC-axis 3 Items
Traverse X-axis 1050 mm
Traverse Y-axis 920 mm
Traverse Z-axis 990 mm
Workpiece weight max. 1200 kg
Workpiece width max. 1050 mm
Workpiece height max 1115 mm
Main spindle speed max. 12000 rpm
Tool interface [type] BT-50 HSK-A100 SK-50
Tool stock min. (standard) [items] 60 Piece
Control (manufacturer) Fanuc G-Tech 31 iB
Machine manufacturer (list selection) nomen nominandum

further specifications

X-Y-Z-axis rapid linear traverse max. 60-60-60 m/min
Tool diameter max. 320 mm
Tool length max. 600 mm
Tool weight max. 20 kg
Main spindle power max. (100% c.d.f.) 26.0 kW 30.0 kW
Main spindle torque max. (100% c.d.f.) 451 Nm

Contact us

First name *

Surname *

E-mail address *

Your message *

The personal data you provide will be forwarded directly to the provider for the purpose of establishing contact. It will not be stored by us.

Notes on privacy policy

Report ad

Reason *

E-mail address *

Your message *

The personal data you provide will be forwarded directly to the provider for the purpose of establishing contact. It will not be stored by us.

Notes on privacy policy

Description

This machine is characterised by maximum working space with a minimum footprint, maximum precision and high acceleration and speeds. The outstanding torque of the spindle and the flexibility in automation are also impressive. The machine processes workpieces up to a diameter of Ø 1,050 x H 1,115 mm and a weight of up to 1,200 kg.
